Technology
|
Printing Method
|
PrecisionCore™ TFP print head
|
Ink Technology
|
Ultrachrome® XD3
|
Print
|
Number of colours
|
6 colour
|
Colours Capacity
|
Photo Black [350ml, 700ml], Matte Black [350ml, 700ml], Cyan [350ml, 700ml], Yellow [350ml, 700ml], Magenta [350ml, 700ml], Red [350ml, 700ml]
|
Minimum Droplet Size
|
3.5 pl, With Variable-Sized Droplet Technology
|
Minimum line width
|
0.02 mm
|
Line accuracy
|
+/-0.26
|
Print Speeds (CAD A1 page size)
|
Quick2 ppm
|
Print from
|
PC, MAC, Network, Mobile Device, Cloud, Direct USB
|
Printing Resolution
|
1,200 x 2,400 DPI
|
Printing Resolution - Draft
|
300 x 600 DPI
|
Printing Resolution - Maximum Quality
|
2,400 x 2,400 DPI
|
Printing Resolution - Speed
|
300 x 600 DPI
|
Paper / Media Handling
|
Paper Formats
|
17" (43.2 cm) Roll, 24" (61.0 cm) Roll, Custom width and length, A1, A2+, A3+, A4 (21.0x29.7 cm)
|
Thickness
|
Single Sheet0.1 mm, Roll0.8 mm, Rigid board suppported
|
Auto Take Up Reel
|
Yes
|
Printable Length
|
Roll91
|
Roll Capacity - Diameter
|
Roll 1:170 mm, Roll 2:170 mm
|
Roll Capacity - Weight
|
Roll 1:6,800 g, Roll 2:6,800 g
|
Borderless printing on
|
20 inches, 10" (25.4cm) Roll, 17" (43.1cm) Roll, 24" (60.9cm) Roll
|
General
|
Power consumption
|
75 Watt, 32 Watt (economy), 0.3 Watt (standby)
|
Product dimensions
|
1,365 x 499 x 975 mm (Width x Depth x Height)
|
Product weight
|
116 kg
|
Mobile and Cloud printing services
|
Apple AirPrint, Epson Cloud Solution PORT, Epson Smart Panel App
|
What's in the box
|
AC adapter, Adobe PostScript 3, Ink set, Installation/safety manual, Maintenance boxes, Setup guide, Spindle Unit(s), SureColor T-Series Printer, Warranty Documents
|
Optional extras
|
Cover Plus warranty extensions, SSD (Solid State Drive), NFC Card Reader (Server), NFC Card Reader (Serverless)
|
Other Features
|
Memory
|
4 GB
|
Emulations
|
PDF 1.7, HP-GL2, RTL, Adobe® Postscript 3®, ESC/P-R, PostScript 3
|
Optional storage
|
1TB SSD
|
Features
|
Touchscreen, Bluetooth, Direct print from USB, Auto Take up Reel, Nozzle Verification Technology
|
Optional Software & Solutions
|
Epson Print Automate, Dinax Mirage, Epson Cloud Solution PORT, Epson Print Layout, Epson LFP Accounting Tool, Epson Device Admin
|
Security
|
SNMP V3, IPSec, AES-256, Data Encryption, NFC - Card Authentication Reader, TMP (Trusted Platform Module), LDAP, IEEE802, SSL/TLS, Panel Admin Mode
|
Media Handling
|
Auto cutter, Auto take up reel, Borderless Print
|
Other
|
Warranty
|
12 months On-site service
|
Country of Origin
|
Country Of Origin
|
Indonesia
|
