Technology
|
|
Printing Method
|
PrecisionCore™ Print Head
|
|
Nozzle Configuration
|
1,600 Nozzles Black
|
|
Minimum Droplet Size
|
3.8 pl, With Variable-Sized Droplet Technology
|
|
Ink Technology
|
DURABrite™ Ultra
|
|
Category
|
Office Workgroup
|
|
All-in-One Functions
|
Print
|
|
Print
|
|
First Page Out
|
Monochrome4.8 Seconds
|
|
Printing Speed ISO/IEC 24734
|
25 pages/min Monochrome
|
|
Duplex Printing Speed ISO/IEC 24734
|
16 A4 Pages/min Monochrome
|
|
Printing Speed
|
34 pages/min Monochrome (plain paper 75 g/m²)
|
|
Printing Resolution
|
1,200 x 2,400 DPI
|
|
Printing Volume
|
70,000 pages per month
|
|
Recommended Duty Cycle
|
500 - 5,000 pages per month
|
|
Colours
|
Black
|
|
Print from
|
PC, MAC, Network, Mobile Device, Direct USB, PC (Wired), PC (Wireless), Mobile Device (WiFi Direct), Mobile Device (Wireless)
|
|
Scan
|
|
Scanning Speed
|
30 ipm ( Monochrome, Single-sided, 200 dpi, ADF ); 30 ipm ( Colour, Single-sided, 200 dpi, ADF ); 60 ipm ( Monochrome, Double-sided, 200 dpi, ADF ); 60 ipm ( Colour, Double-sided, 200 dpi, ADF ); 5 ipm ( Monochrome, Single-sided, 200 dpi, Flatbed ); 5 ipm ( Colour, Single-sided, 200 dpi, Flatbed );
|
|
Optical Resolution
|
1,200 DPI x 2,400 DPI (Horizontal x Vertical)
|
|
Advanced document integration
|
Scan to Email, Scan to FTP, Scan to Network folders, Scan to USB, Computer (Epson Document Capture Pro), Microsoft SharePoint with Epson Document Capture Pro
|
|
Maximum scan size
|
216 mm x 297 mm
|
|
Output formats
|
BMP, JPEG, TIFF, multi-TIFF, PDF(Colour/Greyscale), PNG
|
|
Scanner type
|
Contact image sensor (CIS)
|
|
Fax
|
|
Type of fax
|
Walk-up black and white and colour fax capability
|
|
Fax Transmission Speed
|
Up to 33.6kbps / Approx. 3 sec/page
|
|
Error correction mode
|
CCITU/ITU Group3 fax with Error Correction Mode
|
|
Fax speed dials (max)
|
200 names and numbers
|
|
Page memory
|
Up to 550 pages/ 6MB (ITU-T No. 1 chart)
|
|
Fax Functions
|
PC Fax, Fax to E-mail, Memory Reception, Auto Redial, Fax to Folder, Broadcast Fax, Fax Preview, Polling Reception
|
|
Copy
|
|
Copy Speed
|
Up to 22 ipm Black *Simplex ADF 600 x 600 dpi (ISO/ IEC 24735)
|
|
Copy resolution (dpi)
|
600 x 1200
|
|
Reduction / Enlargement
|
25 % - 400 %
|
|
Maximum number of copies
|
999
|
|
Maximum Copy Size
|
A4
|
|
Connectivity
|
|
Network Printing Protocols
|
IPP, LPD, Port 9100, WSD
|
|
Network Management Protocols
|
SNMP, HTTP, DHCP, BOOTP, APIPA, DDNS, mDNS, SNTP, SLP, WSD, LLTD, Ping
|
|
Network Protocol
|
HTTPS, IPv4, IPv6, SNMP TCP/IPv4, TCP/IPv6, UDP, HTTP, HTTPS, IPSEC, SSL/TLS
|
|
Network Scanning Protocols
|
WSD-Scan, FTP, SMB 1.0, SMB 2.0
|
|
Interfaces
|
Hi-Speed USB - compatible with USB 2.0 specification, Ethernet Interface (1000 Base-T/ 100-Base TX/ 10-Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, Wi-Fi Direct, Wireless LAN a/n (5GHz)
|
|
WLAN Security
|
WEP 64 Bit, WEP 128 Bit, WPA PSK (TKIP), WPA2 Enterprise, WPA2 PSK (AES), WPA3-SAE(AES)
|
|
Paper / Media Handling
|
|
Paper Formats
|
A4 (21.0x29.7 cm), A5 (14.8x21.0 cm), A6 (10.5x14.8 cm), B5, B6, C4 (Envelope), C5 (Envelope), C6 (Envelope), DL (Envelope), No. 10 (Envelope), Letter, 9 x 13 cm, 10 x 15 cm, 13 x 18 cm, Legal, User defined
|
|
Automatic Document Feed
|
50 pages
|
|
Compatible Paper Weight
|
64 - 256g/m²
|
|
Duplex
|
Yes
|
|
Standard Paper input
|
330 Sheets Standard, 80 Sheets MP tray, 250 Sheets paper tray
|
|
Output Tray Capacity
|
150 Sheets
|
|
Paper Tray Capacity
|
330 Sheets Standard, 1,830 Sheets Maximum
|
|
Standard paper tray(s)
|
80-Sheet Multi-Purpose Tray, 250-sheet paper tray
|
|
Optional paper tray(s)
|
3 x 500 sheet paper tray
|
|
Maximum paper input
|
1,830
|
|
Rear paper path (special media)
|
Yes
|
|
Number of paper trays
|
4
|
|
Paper Feed
|
|
Paper Input Name
|
MPT C1 C2-C4 Duplex
|
|
Paper Formats
|
A4, A5, A6, C4 (Envelope), C5 (Envelope), C6 (Envelope), DL (Envelope), No. 10 (Envelope), Letter, User defined, Legal A4, A5, A6, Letter A4, Letter A4, A5, A6, B5, B6, Letter, HLT, Legal, Executive
|
|
Compatible paper weight
|
64 g/m² - 256 g/m² 64 g/m² - 160 g/m²
|
|
Paper Capacity 1
|
80 Sheets of Plain Paper, Postcards, Glossy paper, Envelopes, Labels, 80gsm 250 Sheets of Plain Paper, Envelopes, 80gsm 500 Sheets of Plain Paper, 80gsm
|
|
Media type
|
Plain Paper, Recycled Paper, Colour Paper, Letterhead, Glossy Photo Paper Plain Paper, Recycled Paper, Colour Paper, Letterhead
|
|
General
|
|
Energy Use
|
30 Watt (standalone copying, ISO/IEC 24712 pattern), 1.2 Watt (sleep mode), 15.4 Watt (Ready), 0.2 Watt (Power off), TEC 0.19 kWh/week
|
|
Supply Voltage
|
AC 100 V - 240 V, 50 Hz - 60 Hz
|
|
Product dimensions
|
425 x 535 x 357 mm (Width x Depth x Height)
|
|
Product weight
|
19 kg
|
|
Noise Level
|
6.5 B (A) according to ISO 7779 pattern with Epson Premium Glossy Photo Paper / Photo RPM mode - 50 dB (A) according to ISO 9296
|
|
Compatible Operating Systems
|
MAC OS 10.15 + or later, Mac OS 10.10.x, Mac OS X 10.11.x, Mac OS X 10.12.x, Mac OS X 10.13.x, Mac OS X 10.9.5 or later, Windows 10 (32/64 bit), Windows 11, Windows 7 (32/64 bit), Windows 8 (32/64 bit), Windows 8.1 (32/64 bit), Windows Server 2003 R2 x64, Windows Server 2003 SP2, Windows Server 2008 (32/64bit), Windows Server 2008 R2, Windows Server 2012 (64bit), Windows Server 2012 R2, Windows Server 2016, Windows Vista (32/64 bit), Windows XP Professional x64 Edition SP2 or later, Windows XP SP3 or later (32-bit), macOS 11 or later
|
|
Sound Power
|
Operation:6.5 B (A)
|
|
Noise
|
Operation:50 dB (A)
|
|
Mobile and Cloud printing services
|
Epson Connect (iPrint, Email Print, Remote Print Driver, Scan-to-Cloud), Apple AirPrint, Mopria
|
|
Power supply
|
100V, 240V
|
|
What's in the box
|
Driver and Utilities (CD), Initialization Ink Supply Units, Quick Setup Guide, User manual (CD), Warranty Documents
|
|
Additional Features
|
|
Memory
|
2,048 MB
|
|
Features
|
Touchscreen, Direct Print, Direct scan-to-print without PC, Direct print from USB
|
|
Panel
|
Type: Color, Touch-panel, Diagonal:10.9 cm
|
|
Media Handling
|
ADF 2-sided copy (A4, plain paper), ADF 2-sided scan (A4, plain paper), Automatic duplex (A4, plain paper), Portrait & Landscape printing, Thick Media Support
|
|
Security Functions
|
Limit access function with Epson Web Config, Secure confidential printing with PIN code release, IPsec, IEEE802.1x, SSL (Server authentication), Panel Admin Mode
|
|
Product Safety
|
|
Product Safety Warnings
|
Contains 1,2-benzisothiazol-3(2H)-one. May produce an allergic reaction. Always follow the information on the product label
|
|
Other Features
|
|
Emulations
|
PCL5c, PCL5e, PCL6, PostScript 3, GDI, PDF 1.7
|
|
Optional Software & Solutions
|
Epson Device Admin, Mopria, Epson Print Admin
|
|
Security
|
TLS V1.2, TLS V1.3, SSL, SNMP, SNMP V3, IPSec, FTP, IPv6, HTTPs, WPA2, WPA3, PIN code Release, User Authorisation, IEEE802, SSL/TLS
|
|
Country of Origin
|
|
Country Of Origin
|
Indonesia
|
