Technology
|
Printing Method
|
PrecisionCore™ Micro TFP printhead
|
Ink Technology
|
Ultrachrome® Pro12
|
Print
|
Colours
|
Photo Black, Matte Black, Cyan, Light Cyan, Yellow, Vivid Magenta, Vivid Light Magenta, Violet, Orange, Green, Grey, Light Grey
|
Colours Capacity
|
Photo Black [700ml, 350ml], Matte Black [700ml, 350ml], Cyan [700ml, 350ml], Light Cyan [700ml, 350ml], Yellow [700ml, 350ml], Vivid Magenta [700ml, 350ml], Vivid Light Magenta [700ml, 350ml], Violet [700ml, 350ml], Orange [700ml, 350ml], Green [700ml, 350ml], Grey [700ml, 350ml], Light Grey [700ml, 350ml]
|
Minimum Droplet Size
|
3.5 pl, With Variable-Sized Droplet Technology
|
Ink tank capacity
|
700 ml, 350 ml
|
Nozzle Configuration
|
800 Nozzles Black, 800 Nozzles per Color
|
Printing Resolution
|
1,200 x 2,400 DPI
|
Colour Profiles
|
LUT, ICC Profile
|
Paper / Media Handling
|
Paper Formats
|
A1, A2 (42.0x59.4cm), A2+, A2++, A3+, A3++, A3 (29.7x42.0 cm), A4 (21.0x29.7 cm), 17", 24", B2 (51.4x72.8 cm), B3, B4
|
Compatible Paper Thickness
|
0.08 mm - 1.5 mm
|
Borderless printing on
|
10 inches, 11.81 inches, 12.95 inches, 15.98 inches, 17.01 inches, 20.28 inches, 23.39 inches, 24.02 inches, 20 inches
|
General
|
Power consumption
|
85 Watt, 32 Watt (economy), 3.4 Watt (standby), 0.3 Watt (Power off)
|
Supply Voltage
|
AC 100 V - 240 V, 50 Hz - 60 Hz
|
Product dimensions
|
1,401 x 667 x 1,218 mm (Width x Depth x Height)
|
Product weight
|
121.7 kg
|
Sound Power
|
Operation:7.5 B (A)
|
Noise Level
|
Operation (Roll):49.5 dB (A)
|
Other Features
|
Memory
|
Printer: 2 GB
|
Emulations
|
ESC/P-R, Adobe® Postscript 3® (optional)
|
Features
|
Touchscreen
|
Interfaces
|
Ethernet Interface (1000 Base-T/ 100-Base TX/ 10-Base-T), Hi-Speed USB - compatible with USB 2.0 specification
|
Other
|
Warranty
|
12 months On-site service
|
LCD and Memory Cards
|
Panel
|
Type: Color, Touch-panel
|
