Technology
|
Printing Method
|
PrecisionCore™ Micro TFP printhead
|
Ink Technology
|
Ultrachrome® PRO
|
Print
|
Colours
|
Photo Black, Matte Black, Cyan, Light Cyan, Yellow, Vivid Magenta, Vivid Light Magenta, Grey, Light Grey, Dark Grey
|
Minimum Droplet Size
|
3.5 pl, With Variable-Sized Droplet Technology
|
Ink tank capacity
|
700 ml
|
Nozzle Configuration
|
800 Nozzles Black, 800 Nozzles per Color
|
Printing Resolution
|
2,400 x 1,200 DPI
|
Paper / Media Handling
|
Paper Formats
|
A0, A1, A2 (42.0x59.4cm), A2+, A2++, A3+, A3++, A3 (29.7x42.0 cm), A4 (21.0x29.7 cm), B0, B1 (72.8x102.8 cm), B2 (51.4x72.8 cm), B3, B4, 44", 17", 24", 36"
|
Compatible Paper Thickness
|
0.08 mm - 1.5 mm
|
Borderless printing on
|
10 inches, 11.69 inches, 11.81 inches, 12.95 inches, 15.98 inches, 17.01 inches, 20.28 inches, 23.39 inches, 24.02 inches, 28.66 inches, 33.11 inches, 35.98 inches, 44.02 inches
|
General
|
Power consumption
|
95 Watt, 2.8 Watt (economy), 0.5 Watt (standby), 0.5 Watt (Power off)
|
Supply Voltage
|
AC 100 V - 240 V, 50 Hz - 60 Hz
|
Product dimensions
|
1,879 x 976 x 1,145 mm (Width x Depth x Height)
|
Product weight
|
126 kg
|
Sound Power
|
Operation: 6.7 B (A)
|
Noise Level
|
Operation (Roll): 50.5 dB (A)
|
Other Features
|
Emulations
|
ESC/P-R, Adobe® Postscript 3® (optional)
|
Interfaces
|
Ethernet Interface (1000 Base-T/ 100-Base TX/ 10-Base-T)
|
Media Handling
|
Borderless Print, Roll Paper, Thick Media Support
|
Other
|
Warranty
|
12 months On-site service
|
