General
|
Printer type
|
Colour
|
Display
|
Colour touchscreen
|
Display size
|
6.8cm touchscreen
|
Max paper size
|
A3
|
Memory
|
128MB
|
Technology
|
Inkjet
|
Function
|
Print, Copy and Scan
|
Brother Apps
|
Creative Center
|
Yes
|
Note Scan
|
Yes
|
Outline and Copy
|
Yes
|
Outline and Scan
|
Yes
|
Connectivity
|
Connectivity
|
Wireless
|
Local interface
|
Hi-Speed USB 2.0
|
Wi-Fi Direct
|
Yes
|
Wireless network interface
|
802.11b/g/n
|
Mobile connectivity
|
Supported
|
AirPrint, Google Cloud Print, iPrint&Scan, Wi-Fi Direct
|
Copying
|
Resolution
|
Up to 1,200 x 1,200dpi (colour and mono)
|
Speed
|
12ipm (mono) and 9ipm (colour)Up to 12ipm (mono) & 9ipm (colour)
|
Dimensions & weights
|
With carton
|
573 (W) x 238 (D) x 403 (H)mm 10.1 kg
|
Without carton
|
480 (W) x 290 (D) x 163 (H)mm
|
Weight
|
8.1 kg
|
Environmental
|
Blue Angel environmental accreditation
|
Yes
|
Energy Star environmental accreditation
|
Yes
|
Nordic Swan environmental accreditation
|
Yes
|
Power consumption (Watts)
|
Operating: 23W, Ready Mode: 5.0W, Sleep Mode: 1.3W, Off: 0.04W
|
Sound pressure
|
50dB (A) (Average)
|
In the box
|
Contents
|
Power supply cord, Product safety guide, Software disc, Supplies, User guide, Warranty card, Quick setup guide
|
Media specifications
|
Types and sizes
|
Standard Tray: A4, LTR, EXE, A5, A6, Photo, Indexcard, Photo-2L, Com-10, DL Envelope, Monarch. Manual Feed Slot: A4, LTR, EXE A3, LGR, LGL, A5, A6, Photo, Indexcard, Photo-L, Photo-2L, C5, Com-10, DL Envelope, Monarch
|
Weights
|
Standard Tray: Plain, Inkjet, Glossy(cast/resin) 64-220g/m2. Manual Feed Slot: Plain, Inkjet, Glossy(cast/resin) 64-220g/m2. Auto Duplex: Plain 64-120g/m2.
|
Network
|
Wireless network
|
802.11b/g/n
|
Wireless network security
|
WEP 64/128bit, WPA-PSK(TKIP/AES), WPA2-PSK(AES)
|
Operating systems & software
|
Software supplied - Mac
|
Brother ControlCenter2, NewSoft® OCR
|
Software supplied - Windows
|
Brother ControlCenter4, Nuance® Paperport® 12 SE with OCR
|
Supported
|
Windows® 7 (32bit(x86) & 64bit(x64) editions), Windows® 8 (32bit(x86) & 64bit(x64) editions), Windows Vista® (32bit(x86) & 64bit(x64) editions), Windows® XP Professional (32bit(x86) & 64bit(x64) editions), Windows® XP Home, Windows Server® 2003 & 2008 (32bit(x86) & 64bit(x64) editions),Windows Server® 2008 R2 & 2012 (64bit(x64) edition), OS X v10.7.5/10.8.x/ 10.9.x
|
Paper handling
|
Paper input
|
150 sheet standard paper tray, 1 Sheet Manual Feed Slot
|
Paper output
|
50 sheets
|
Printing
|
Resolution
|
Up to 6,000 x 1,200 dpi (Vertical x Horizontal)
|
Speed - fast mode
|
Up to 35ppm mono & 27ppm colour
|
Speed - laser comparable
|
20ipm mono & 18ipm colour
|
Automatic 2 sided print
|
Yes
|
Droplet size
|
1.5 pico litre
|
Scanning
|
Resolution
|
Optical: From Flatbed Up to 2,400 x 1,200dpi. Interpolated: Up to 19,200 x 19,200dpi
|
Scan to
|
Email, OCR, Image, File, Card, USB Flash Memory Drive, FTP, Network* *Windows® only
|
Speed
|
From 3.37 seconds mono & colour (A4 size, 100 x 100dpi)
|
Solutions
|
Supported
|
AirPrint, Box, BR-Docs (US/UK/GER/FRA only), Cortado Cloud Print, Dropbox, Evernote, Evernote Business, Facebook, Flickr, Google Cloud Print, Google Drive, iPrint&Scan, Managed Print Services, OneDrive, OneNote, Picasa
|
Supplies and accessories
|
Brother paper
|
BP71GA3: A3 glossy photo paper, 20 sheets, BP71GLA: A4 glossy photo paper, 20 sheets, BP71GLP: 10x15 cm glossy photo paper, 20 / 50 sheets, BP60MA: A4 Matte inkjet paper, 25 sheets, BP60PA: A4 inkjet paper, 250 sheets
|
High yield ink cartridges
|
Black: LC227XL BK - Approx 1,200 A4 pages Cyan / Magenta / Yellow: LC225XL C/M/Y - Approx 1,200 A4 pages. Cartridge yield is declared in accordance with ISO/IEC 24711
|
Standard yield ink cartridges
|
Black: LC223BK - Approx 550 A4 pages, Cyan / Magenta / Yellow: LC223C/M/Y - Approx 550 A4 pages. Cartridge yield is declared in accordance with ISO/IEC 24711
|
Direct printing/scanning
|
Print from
|
PictBridge, USB Flash Memory Drive, Memory Stick Duo/Pro Duo/Micro, Secure Digital (SD), Secure Digital, High Capacity (SDHC), Secure Digital Extended Capacity (SDXC), Multimedia Card, Multimedia Card Plus, Multimedia Card Mobile
|
Warranty
|
Warranty
|
Two Year Back to Base Warranty
|
