Caveats
|
*
|
*Requires USB Type-C connection with 15W power source (not included)
|
General
|
Usage type
|
Desktop, Portable
|
Backup clock
|
Yes
|
Control panel
|
LED, Keys
|
Display
|
Colour touchscreen
|
Display size
|
7.1cm (2.8") LCD
|
Connectivity
|
USB interface
|
USB Type-C *Requires USB Type-C connection with 15W power source (not included), USB 2.0 Host (Rear, up to 128GB)
|
Wi-Fi Direct
|
802.11g/n
|
Wireless network interface
|
2.4GHz: IEEE 802.11b/g/n (Infrastructure Mode)
|
Dimensions & weights
|
With carton
|
W 369 x D 158 x H 200 mm 3.46 kg
|
Without carton
|
W 288 X D 101 X H 85 mm input tray closed
|
Weight
|
1.42 kg
|
Energy Consumption
|
Operating
|
Up to 12 watts
|
Ready mode
|
6.4 watts
|
Sleep mode
|
Up to 1.5 watts
|
Off
|
0.1 watts
|
Environment
|
Operating humidity
|
20 to 80%
|
Operating temperature
|
5 to 35 degrees celsius
|
Sound power
|
62dB
|
In the box
|
Device
|
Yes
|
Product safety guide
|
Yes
|
USB cable
|
Yes
|
Quick setup guide
|
Yes
|
Media specifications
|
Types and sizes
|
Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Non carbon paper, Receipt, Business Card, Plastic Card
|
Weights
|
51.8 - 128 gsm, Paper 0.08 ~ 0.14mm, Plastic card thickness embossed up to 1.24mm or without emboss 0.75-1.02mm
|
ADF media sizes
|
Paper : width 51 - 215.9mm, height 70 - 355.6mm, Plastic card: width min/max 51-55mm, length min/max 80-90mm, Long Paper 5000mm (300dpi 1-sided single paper)
|
Network
|
IPv4
|
DHCP, APIPA (Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, SMTP Client, FTP/SFTP Client, SMB Client(SMB1.0/2.0/2.1) (=CIFS Client), SNMPv1/v2c/v3, HTTP/HTTPS server, ICMP, Web Services(Scan), SNTP Client
|
IPv6
|
RA, DNS Resolver, mDNS, LLMNR responder, SMTP Client, FTP Client, SMB Client(SMB1.0/2.0/2.1) (=CIFS Client), HTTP/HTTPS server, ICMPv6, Web Services(Scan), SNTP Client, SNMPv1/v2c/v3
|
Wireless network security
|
SMTP-AUTH, SSL/TLS (HTTPS, SMTP), SNMP v3, SSH, 802.1x (EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES)
|
Wireless setup support
|
Yes
|
Operating systems & software
|
Supported OS
|
For full list of compatible operating systems visit support.brother.com
|
Software supplied - Mac
|
Brother iPrint&Scan for Desktop, Kofax Power PDF Standard v3, Remote Setup
|
Software supplied - Windows
|
Brother iPrint&Scan for Desktop, Kofax PaperPort 14SE with OCR, Kofax Power PDF Standard v5, Remote Setup, Easy Setup
|
Scanning
|
2-Sided scan
|
Yes
|
A4 Scan Speed
|
30
|
ADF
|
20
|
Scan to
|
Scan to PC (Image), Network (SMB), Email Server, Workflow, FTP/SFTP, SharePoint (On Premise), Brother Webconnect, Brother Cloud Apps
|
Drivers
|
TWAIN, WIA, AirPrint Scan (Driverless) SANE
|
Greyscale
|
256 levels
|
Interpolated scan resolution
|
1200 x 1200
|
Scan resolution from ADF
|
600 x 600
|
Supplies and accessories
|
Optional accessories
|
Carrier Sheet CS-A3301, Pick-up Roller PUR-2001C, Separation Pad SP-2001C, Output Tray OT-1001C, Legacy Kit (LK-1001CEU, LK-1001CUK), USB Power Adapter (PA-AD-004EU, PA-AD-004UK)
|
Warranty
|
Warranty
|
12 months
|
